Flex software version 8.27.0.0 expands Korhex new possibilities for VAG group MDG1 Bosch ECUs with TC298 and TC299 processors.
With the VFI – Voltage Fault Injection technology, Korhex now can unlock these Bosch MDG1 control units, following a procedure that reduces intervention times and avoids working directly on the PCB.
How to do?
1. Require FLS0.20M/S Boot Glitch license or Flex Full FLS0.5M/S configuration
2. Unlock VAG MD1 MG1 ECU with Flex protocol and Korhex Boot Glitch Tool
3. Read and write ECU directly in Bench mode, simplifying the programming process further.
- Memories: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Backup
- License: Connection: ~30 seconds
- Reading Time: ~2 minutes 30 seconds
- Writing Time: ~2 minutes
Which VAG MDG1 ECUs Are Supported?
- VAG Bosch MG1CS002 H80 – TC298
- VAG Bosch MG1CS008 – TC298
- VAG Bosch MG1CS031 H80 – TC298
- VAG Bosch MD1CS004 H80 – TC298
- VAG Bosch MD1CS014 – TC299
Some of the supported vehicles
- Audi SQ5 (II) FY (2021MY) 3.0L V6 TDI 24v MHEV 336HP
- Audi RS5 (II) F5 (2022MY) 2.9L V6 Twin-Turbo 24v 444HP
- Cupra Formentor (I) SE316 (2021MY) 2.0L TSI 16v 187HP
- Lamborghini Urus S (I) (2022MY) 4.0L V8 Twin-Turbo 32v 657HP
- Volkswagen (VW) Golf (VIII) (2021MY) 2.0L TDI 16v 197HP
